Flexible Power Roller Conveyor ,Extensible motorized roller conveyor for handing Conveyor

FOB Reference Price:Get Latest Price
US $100-1,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
ALLY LOGISTICS
Model Number:
ALA003
Type::
Single roller Conveyor
Material::
Carbon Steel with ZINC coating
Load Capacity::
Max 50Kgs
Hight Adjustable ::
800--1000mm
Roller Dia::
38,50 ,60mm
SupplyAbility
SupplyAbility:
100 Meter/Meters per Week
Packaging & Delivery
Packaging Details
standard export package
Port
Shanghai,Ningbo
Lead Time :
15--45days

Company 2.jpg

.jpg



Product Description:

 Features:

1. Extensible conveyor is used to solve problems on transport in such complicated environment as warehousing, packing line and loading/unloading etc., and can handle all sizes of boxed packages with flat bottom.

2. It has an advantage over fixed conveyors in flexibility and movability. It makes skillful use of movement, expansion and compaction so that floor space required can be reduced remarkably.

3. This conveyor is a complete steel structure, with flexibility. And it can be laid out at your request.

4. Multiple Extendable conveyors can be connected together and can be expandable optionally to any length required.



 We have four types: single roller flexible conveyor, double rollers flexible conveyor, skate wheel flexible conveyor and motorized roller flexible conveyor.


Support legs: By turning the handle, height of support legs can be adjusted. Even the floor is not level, Extendable conveyor can stand stably and handle packages smoothly. Height of support legs is adjusted to form an inclined conveying surface. Packages flow much more smoothly and labour strength of operator is reduced. Height adjustable of support legs: 800-1000mm.



Casters: Dia. 150mm heavy-duty casters are used. On two ends of Extendable conveyor, castors brake are provided. They stand firmly when handling packages.



Load Capacity: When complete expanding, load capacity per unit(between support legs) is not more than 80 KGS (in the state of no impact load).



Technical data:                                           1p9p.jpg
